Function introduction

American stadard chain G43
NACM96
HIGHTEST CHAIN ASTM96（G43）
TRADE SIZE		DIA		working load limit		proof test		breaking load min		total lengh 100link		total weight per 100 FT
MM	IM	MM	IM	KG	LBS	KN	LBS	KN	LBS	MM	IM	MM	IM
7	1/4	7	0.276	1180	2800	17.3	3900	34.6	7800	31.5	1.24	9.8	0.38
8.7	5/16	8.7	0.343	1770	3900	26	5850	52	11700	32.8	1.29	11.2	0.44
10	3/8	10.3	0.406	2450	5400	36	8100	72	16200	35	1.38	14	0.55
11.9	7/16	11.9	0.468	3270	7200	48	10800	96	21600	41.6	1.64	16.6	0.65
13	1/2	13.5	0.531	4170	9200	61.3	13800	122.6	27600	45.5	1.79	18.2	0.72
16	5/8	16	0.63	5910	13000	86.5	19500	173	39000	56	2.2	20	0.79
20	3/4	20	0.787	9180	20200
22	7/8	22	0.866	11140	24500
TRANSPORT CHAIN ASTM96(G70)
TRADE SIZE		DIA		working load limit		proof test		breaking load min		total lengh 100link		total weight per 100 FT
MM	IM	MM	IM	KG	LBS	KN	LBS	KN	LBS	MM	IM	MM	IM
7	1/4	7	0.281	1430	3150	28	6300	56	12600	31.5	1.24	9.8	0.38
8.7	5/16	8.7	0.343	2130	4700	41.8	9400	83.6	18800	32.8	1.29	11.2	0.44
10	3/8	10.8	0.406	2900	6600	58.7	13200	117.4	26400	35	1.38	14	0.55
11.9	7/16	11.9		3970	8750	77.8	17500	155.4	35000	41.6	1.64	16.6	0.65
13	1/2	13		5130	11300	100.4	22600	200.8	45200	45.5	1.79	18.2	0.72
16	5/8	16		7170	15800	140.4	31600	280.8	63200	56	2.2	20	0.79
20	3/4	20		11200	24700	219.6	49400	439.2	98800	70	2.76	25	0.98
PROOF COIL CHAIN NACM96(G30)
TRADE SIZE		DIA		working load limit		proof test		breaking load min		total lengh 100link		total weight per 100 FT
MM	IM	MM	IM	KG	LBS	KN	LBS	KN	LBS	MM	IM	MM	IM
4	1/8	4	0.156	180	400	3.6	800	7.2	1600	23.9	0.94	6.4	0.25
5.5	3/16	5.5	0.217	365	800	7.2	1600	14.4	3200	24.8	0.98	7.7	0.3
7	1/4	7	0.276	580	1300	11.6	2600	23.2	5200	31.5	1.24	9.8	0.38
8	5/16	8	0.331	860	1900	16.9	3800	33.8	7600	32.8	1.29	11.2	0.44
10	3/8	10	0.394	1200	2650	23.6	5300	47.2	10600	35	1.38	14	0.55
11.9	7/16	11.9	0.488	1680	3700	32.9	7400	65.8	14800	41.6	1.64	16.6	0.65
13	1/2	13	0.512	2030	4500	40	9000	80	18000	45.5	1.79	18.2	0.72
16	5/8	16	0.63	3130	6900	61.3	13800	122.6	27600	56	2.2	20	0.79
20	1/2	20	0.787	4800	10600	94.3	21200	188.6	42400	70	2.76	25	0.98
22	3/4	22	0.866	5810	12800	114.1	25600	288.2	51200	77	3.03	27.5	1.05
26	1/1	26	1.02	8140	17900	159.1	35800	318.2	71600	90.9	3.58	31.7	1.25

American stadard chain NACM96

Add time：2022-01-21 09:06:54 Number of views：659
